Ultrapure And Pure, Eiectrodeionzation,4

1. Large-screen color touch liquid crystal display with intelligent operation human-machine interface.
2. Dual password protection, including user password protection and initial password for factory mode protection.
3. Possessing timed standby and timed automatic shutdown functions. Once the shutdown time arrives, all outputs will automatically cease and enter the shutdown mode.
4. Comprehensive management functions for RO pure water and ultrapure water generation, system water intake, system circulation, and disinfection.
5. Complete protection functions such as waterless protection, high-pressure water full protection, and fault alarm functions.
6. Timed and quantitative water intake, among a series of powerful functions.
7. Thorough historical alarm, historical water intake record, and consumable lifespan management functions.
8. Equipped with analog pressure sensors and analog liquid level sensors, capable of directly indicating the inlet water pressure and water tank storage volume.
9. Furnished with a USB Host interface, supporting the data export function of historical alarm records and historical water intake records. (Optional)
10. Outfitted with an RS232 communication interface, which can be connected to a micro printer or monitoring software. (Optional)
11. Powered by a low-voltage 24VDC main power supply, conforming to safety norms, suitable for use in humid environments, and causing no harm to the human body.
12. Three-channel water quality monitoring, enabling simultaneous display of RO conductivity value, UP resistivity value, temperature value, raw water TDS value, pressure, and equipment operation status indication.
13. Configured with a 316L stainless steel precision net filter at the front end and built-in dual filter elements for removing particulates and scale; it is cleanable and drainable.
14. The unique long-lasting KDF device utilizes original imported filter material from the United States to remove residual chlorine, heavy metals, and inhibit bacterial growth at the front end of water purification, providing better protection for the post-purification system.
15. 11-inch single 1.5-liter capacity ultrapure column.
16. This machine adopts a dual-pump and dual-membrane process. In regions with poor source water quality and high water hardness, it guarantees stable effluent water quality and longer service life of consumables.
17. All filter connection ports feature a plug-and-pull design, facilitating convenient replacement of the filter column without the need for tools. Disposable integrated filter columns are employed.
18. It has a data storage function, is equipped with a USB interface, and can be externally connected to an SD card for data transmission.

1. Prior to startup: Inspect the water source, power supply and consumables to ensure their normality.
2. At the time of startup: Commence with the water supply, followed by the power supply, and observe the operational status of the equipment.
3. During operation: Regularly monitor the water quality, refrain from frequent startup and shutdown, and maintain the cleanliness of the equipment.
4. When shutting down: Disconnect the power first, then the water. In the case of long-term shutdown, evacuate the system.
5. Maintenance of consumables: Regularly replace filter elements, membranes and other consumables, disinfect at regular intervals, and inspect the sealing property.
6. Abnormal situation handling: In the event of an alarm or abnormal water quality, promptly stop the machine for inspection.
7. Safe operation: Avoid electric shock and scalding, and strictly adhere to the operational procedures.
