1. 7-inch color display, enabling perfect online monitoring of cold drying temperature, output pressure, and output flow. The cold drying status, electrolysis status, water level status, and online leak detection are all clearly visible.
2. Output pressure and tank pressure are monitored by precise pressure sensors, with digital display on the screen, eliminating the need for traditional pointer pressure gauges. It is equipped with a ambient-pressure start-up device, which extends the compressor's lifespan.
3. It has an automatic water replenishment function, controlling the pump to add liquid, eliminating the need for manual water replenishment.
4. The output gas temperature is low,with a dew point better than -70℃,and the moisture content in the output gas is low.
5. It has a memory function for the current startup time and cumulative working time for lab management compliance.
6. It adopts low-temperature cold drying and pressure swing adsorption dehydration technology, avoiding frequent replacement of silica gel and reducing the workload of laboratory personnel.
7. The purification tube is made of high-strength PC material, molded in one piece, resistant to reagents, high temperatures, and impacts.
8. Simple operation, just turn on the power switch to produce gas, with stable output pressure, capable of meeting the needs of multiple gas chromatographic analyses simultaneously.
9. Only need to add KOH solution for the first time, and then only distilled water needs to be added for continuous use.
10. The instrument is equipped with a hydrogen leakage protection function. When hydrogen leaks, the instrument automatically cuts off the power and alarms.
11. The instrument has an overwater protection function to ensure that the gas chromatograph is not damaged.
12. It is equipped with a non-return liquid one-way valve to prevent backflow.
13. It replaces traditional high-pressure hydrogen gas cylinders, making the laboratory more instrumentized.
14. Cold drying, water replenishment, electrolysis, and oxygen removal are all fully automated, truly achieving 24-hour unattended operation.

Precautions
1. Check whether the nut at the hydrogen outlet is securely tightened and whether the upper cover of the purifier is tightly fastened to maintain proper instrument sealing.
2. Monitor the pressure. The pressure value will gradually increase at a slow pace and reach approximately 0.3 MPa within 2 - 3 minutes.
3. Upon power connection, the intake tube automatically initiates liquid replenishment into the system. After complete consumption of the pre-diluted analytical-grade KOH solution, remove the liquid inlet tube from the container and insert it into a bucket filled with distilled water or deionized water. Simultaneously, the "output pressure" value on the screen will start to increase. When the instrument detects a lack of water, it will automatically replenish water.
4. Open the upper cover of the external purifier, replace the adsorbent material, and firmly tighten the upper cover of the sealed purifier before operating the instrument.
5. Maintenance of the electrolytic cell: It is advisable to replace the electrolyte after one year of instrument use. The specific procedure is as follows: Place the instrument on a tabletop, open the liquid discharge port to drain the electrolyte, then rinse it twice with distilled water. After rinsing, add fresh electrolyte according to the electrolyte preparation method.
